StateFlow

StateFlow is a type-safe state management system that guarantees state consistency through immutability, provides explicit signal feedback, and maintains complete state visibility.

Why StateFlow?

Traditional state management suffers from three critical problems:

• State Inconsistency: Mutable state leads to race conditions and unpredictable behavior
• Silent Failures: Invalid transitions are ignored without feedback
• Opaque State: Difficult to understand current state and debug issues

StateFlow solves these with immutable states, explicit signal results, and built-in observability.

Core Architecture

StateFlow uses three key concepts:

// 1. Signals: Commands that trigger state changes
const signals = {
  play: defineSignal("play"),
  setVolume: defineSignal<{ level: number }>("setVolume")
};

// 2. States: Immutable snapshots with variants
const playbackState = defineState<{ position: number; volume: number }>()
  .name("playback")
  .signals(signals)
  .variant("playing")
  .variant("paused", true) // initial variant
  .build();

// 3. Flows: Pure transition logic
defineFlow(playbackState.paused, {
  play: (state) => playbackState.playing(state),
  setVolume: (state, signal) => ({ ...state, volume: signal.level })
});

Quick Example

Here's a minimal example demonstrating StateFlow's key features:

import { defineSignal, defineState, defineFlow, applyFlow, lock } from "@state-flow/core";

// Define your signals
const signals = { increment: defineSignal("increment") };

// Define your state structure
const appState = defineState<{ count: number }>()
  .name("counter")
  .signals(signals)
  .variant("active", true)
  .stringRepr(s => `count=${s.count}`)
  .build();

// Define state transitions
defineFlow(appState.active, {
  increment: (state) => ({ count: state.count + 1 })
});

// Apply to your application
const app = { counter: { count: 0 } };
applyFlow(app, [appState], () => {});

// Dispatch signals with guaranteed feedback
await using send = await lock(app);
await send(signals.increment()).done();
console.log(`${app.counter}`); // "counter.active(count=1)"

The await using syntax requires TypeScript 5.2+ and an ES2022+ target — see Installation for setup details.

Next Steps

Explore the core concepts to understand how StateFlow achieves its guarantees, or jump directly to the API reference for detailed usage information.
